एक्रिलिक रोटामीटर / फ्लोमीटर – F3600

1. Select the Installation Point
Choose a straight section of the pipeline where flow is stable. Avoid installing immediately after bends, valves, or pumps to ensure accurate readings.

2. Ensure Proper Orientation
Install the rotameter in a vertical position with upward flow. Correct orientation is critical for proper float movement and accuracy.

3. Connect to the Pipeline
Fit the inlet and outlet connections directly into the pipeline using appropriate fittings (threaded or union type). Follow the flow direction marking on the rotameter body.

4. Tighten and Secure Connections
Ensure all joints are properly tightened to prevent leakage. Use thread seal tape if required for threaded connections.

5. Start Flow and Check Operation
Run the system and observe the float movement. It should rise smoothly without sticking, indicating proper installation.

6. Verify Reading Stability
Check that the float stabilizes at a consistent level under steady flow conditions. Fluctuations may indicate air, turbulence, or incorrect installation.
